1. Made of silicone with good biocompatibility
2. X-ray opaque line throughout the length
3. Opening with multiple side eyes to facilitate drain
4. Clear tubing provides inspection and drainage visibility
5. Sterile
| Perforated | Length (cm) | Size (Fr) | Cat. No. | Cat. No. (With 150°-bent Trocar) |
| 4 Holes - End | 100 | 12 | N01D031230 | / |
| 4 Holes - End | 100 | 14 | N01D031430 | / |
| 4 Holes - End | 100 | 16 | N01D031630 | / |
| 4 Holes - End | 100 | 18 | N01D031830 | / |
| 4 Holes - End | 100 | 20 | N01D032030 | / |
| 4 Holes - End | 100 | 24 | N01D032430 | / |
| 4 Holes - End | 100 | 26 | N01D032630 | / |
| 4 Holes - End | 100 | 28 | N01D032830 | / |
| 4 Holes - End | 100 | 30 | N01D033030 | / |
| 4 Holes - End | 100 | 33 | N01D033330 | / |
| 4 Holes - End | 100 | 36 | N01D033630 | / |
| 5 Holes - End | 50 | 9 | N01D030910 | / |
| 5 Holes - End | 50 | 12 | N01D031210 | / |
| 5 Holes - End | 50 | 14 | N01D031410 | / |
| 5 Holes - End | 50 | 16 | N01D031610 | / |
| 5 Holes - End | 50 | 18 | N01D031810 | / |
| 5 Holes - End | 50 | 20 | N01D032010 | / |
| 5 Holes - End | 50 | 24 | N01D032410 | / |
| 5 Holes - End | 50 | 26 | N01D032610 | / |
| 5 Holes - End | 50 | 28 | N01D032810 | / |
| 5 Holes - End | 50 | 30 | N01D033010 | / |
| 5 Holes - End | 50 | 33 | N01D033310 | / |
| 5 Holes - End | 50 | 36 | N01D033610 | / |
| 72 Staggered Holes - End | 125 | 7 | N01D060710 | N01D060711 |
| 72 Staggered Holes - End | 125 | 10 | N01D061010 | N01D061011 |
| 72 Staggered Holes - End | 125 | 15 | N01D061510 | N01D061511 |
| 72 Staggered Holes - End | 125 | 19 | N01D061910 | N01D061911 |
| 92 Staggered Holes - Center | 125 | 10 | N01D081010 | N01D081011 |
| 92 Staggered Holes - Center | 125 | 15 | N01D081510 | N01D081511 |
| 92 Staggered Holes - Center | 125 | 19 | N01D081910 | N01D081911 |
• Available with 166°-bent trocar and bendable trocar
• Available with a connector with tube for connecting the drain to a silicone reservoir
(only for 10, 15 and 19 Fr of staggered perforated drain)
• Available with a connector for connecting the drain to a spring reservoir
(only for 10, 15 and 19 Fr of staggered perforated drain)
|
|
|
|
|
|
|
|
|
|
|
|
